8500pcs/Hour Shrink Label Machine Square Curved Bottle Shrink Sleeve Applicator Machine
|
8500pcs/Hour Shrink Label Machine Square Curved Bottle Shrink Sleeve Applicator Machine
| Place of Origin | FOSHAN |
| Brand Name | PINCHI |
| Model Number | NC-350 |
Product Details
Scope Of Application::
Suitable For Use In The Food And Beverage, Pharmaceutical, And Daily Chemical Industries.
Applicable Bottle Types::
Flat Bottles, Square Bottles, Curved Bottles, Cup-shaped Bottles, And Similar Products.
Material::
SUS304 Stainless Steel
Shrink Film Material::
Suitable For PVC, OPS, PET, Etc.
Automatic Grade::
Full Automatic
Warranty::
1 Year
Packing Details::
Export Standerd Wooden Case
Delivery Time::
40 Days
Highlight:
8500pcs/hour shrink label machine
,square Bottle shrink label machine
,curved bottle shrink sleeve applicator machine
Payment & Shipping Terms
Minimum Order Quantity
1SET
Price
10000-20000USD
Packaging Details
WOODEN BOX
Delivery Time
30 WORK DAYS
Payment Terms
T/T
Supply Ability
20 SETS
Product Description
Full Automatic SUS304 Stainless Steel Bottle Shrinking Machine with 8500pcs/hour Capacity for Shrink Sleeve Labeling
Bio 150ml Bottle With 8500pcs /per Hour Full Automatic Shrinking Sleeve Production Line
Product Overview
The fully automatic shrink sleeve labeling machine is an automated device that wraps heat-shrinkable film around specific areas of product containers (such as bottles or cans), typically the labeling zone. By applying heat, the film shrinks to form a tight, aesthetically pleasing packaging effect.
Its operating principle leverages the characteristics of heat-shrinkable materials: during production, the film undergoes stretch orientation. When heated, its molecular chains relax, generating a contraction force.
Sleeve labeling machines are versatile automatic film wrapping machines suitable for round bottles, flat bottles, square bottles, curved bottles, cup-shaped containers, and other similar products in the food and beverage, medical, daily chemical, and other light industrial sectors.
Technical Specifications
| Parameter | Specification |
|---|---|
| Host Size: | 2100L x 1150W x 2000H (mm) |
| Machine Weight: | Approximately 400KG |
| Bottle Diameter Range: | X60-X120 (mm) |
| Bottle Height: | 100-320 (mm) |
| Applicable Bottle Type: | Round |
| Sleeve Product Temperature: | Room Temperature +5℃ |
| Label Length: | 80-285mm (Max) |
| Label Thickness: | 0.035-0.08mm |
| Power Supply: | 220V |
| Operating Speed: | 7200 bottles/hour |
| Power Consumption: | 2.5KW (excluding shrinkage part) |
This model contains 2 metres conveyor belt frame. Bottle shape or size changes require replacement of center guide column, bottle screw, and knife disc. The conveyor belt power in the labeling machine section is controlled by the labeling machine.
Equipment Visuals
Labeling Machine Exterior
Equipment Technical Drawings
Ordering & Delivery Terms
| Item | Details |
|---|---|
| Product Description | Bottle Inspection Machine with VAT |
| Place of Origin | Made in China |
| Price Validation | 100 days |
| Payment Terms | T/T, 30% deposit, 70% to be paid before loading against FAT |
| Delivery Time | 35 days after receipt of advanced payment |
| Warranty | 1 year for complete machine, long term for software & system |
| Commissioning | Free commissioning within 3 days, customer bears engineer's local food, accommodation and tickets, extra time charged at USD 150/day |
After-Sales Service & Support
The overall product quality has traceability, and the product quality warranty period is 1 year, calculated from the date of equipment acceptance.
Free maintenance during the warranty period, with corresponding travel and material costs charged for after-sales service beyond the warranty period.
Daily operation and maintenance services: Our company provides free remote operation and maintenance online services through Pinchi Tech AI cloud platform, particularly for system updates, algorithm settings, software adjustments, etc.
